APPLICATION

• Self-suction, self-priming pump with eccentric vanes
• Composed of two pumps joined by a manifold (on demand)

TECHNICAL FEATURES

• Flow: 200 l/min
• Consumption: 7-12 A
• Pressure: 3 bar
• Motor: 2x1 kW 230 VAC, single-phase, self-ventilated
• Thermal protection
• S1 continuous operation
• IP-55 protection
• 1,500 rpm
• Equipped with recirculation bypass
• Suction: 2.7 m · Delivery: 20 m
• Priming pipe suction: 5 m
• Connection using M1 ½" threads (BSP). The manifold can be built according to specific needs on demand.
• Junction box with key switch
• Anti-rust treatment

Dimensions and weight (approx.):

• Dim.: 400x350x550 mm (LxWxH)
• Weight: 44.5 kg

Optional

• Metallic bedplate trolley with wheels
• Hoses and accessories
• Hose-reel
